CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | CUT100 | Warranty | 1 Year |
|---|---|---|---|
| Weight | 40 | Duty Cycle(%) | 100 |
| Dimension(l*w*h) | 510*265*500 | Type | Cnc Plasma/flame Cutter Machine |
| Rated Input Voltage | AC380V | Power Factor | 0.93 |
| Control mode | IGBT Inverter | Using Plasma Gas | Compressed Air |
| High Light | CUT100 IGBT Plasma Cutter,Portable IGBT Plasma Cutter,IGBT Plasma Portable Steel Cutting Machine |
||
Product Description
Cut100 Mobile Cut Igbt Plasma Cutter Function Portable Steel Cutting Machine
Product charactics
1. Preset current function, can preset accurate cutting current with infinite adjusting way to cut different thickness plate.
2. Better external and dynamic characteristic than transformer type cutting machine, With excellent performance like high successful rates of arc striking, good arc stiffness, smooth cut.
3. Current rising slowly when arc starting, effectively extend the life of electrode and nozzle.
4. Very stable cutting current, it doesn't influence the cutting current when voltage fluctuates within 10%.
5. High duty cycle, no stop at max cutting current.
6. With non-contact arc striking, excellent instant arc strike function.
Product parameters
|
Type |
CUT100 |
|
|
control mode |
IGBT inverter |
|
|
Rated input voltage |
AC380V |
|
|
Rated input current(A) |
22 |
|
|
Rated input capacity(KVA) |
14.5 |
|
|
Rated output current(A) |
100 |
|
|
Cable cross-sectional area |
mains input(mm2) |
4 |
|
power output(mm2) |
16 |
|
|
ground wire(mm2) |
4 |
|
|
Rated output voltage(V) |
120 |
|
|
Duty cycle(%) |
100 |
|
|
Rated no-load voltage(V) |
285 |
|
|
Current adjustment range(A) |
30-100 |
|
|
Quality cutting thickness (carbon steel)(mm) |
1~30 |
|
|
Maximum cutting thickness (carbon steel)(mm) |
35 |
|
|
Using plasma gas |
Compressed air |
|
|
Gas pressure range(MPa) |
0.4-0.5 |
|
|
Applicable air compressor capacity(m3) |
≥0.3 |
|
|
Arc ignition mode |
High pressure non-contact |
|
|
Enclosure rating |
IP21S |
|
|
Insulation rating |
F |
|
|
Cooling method |
Air |
|
|
Power factor |
0.93 |
|
|
Dimensions(mm) |
510*265*500 |
|
|
Host weight(KG) |
40 |
|
FAQ
Q:Can you make your welding machines under my brand?
A:Yes, we can welding machines under your logo and it has the Minimum Order Quantity .
Q:I have not heard of General Welder company before, are you a new company?
A:General Welder company was established since 2012 by a team of members with welding machines exceptional knowledge and with over 10 years of experience in the welding machines Industry.
Q:.Can you offer welding machines for testing?
A:Yes, we can offer welding machines for the test.
Q:What kind of welding machines warranty do you have?
A:We provide a 1-year warranty to most of our welding machines product. For more information, please send the product model and send an email to us.
