CUTC60 AC380V Portable Plasma Cutter IP21 For Stainless Steel Copper Metal
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Brand | Gowellde | Type | CUT60 |
|---|---|---|---|
| Warranty | 1 Year | Voltage | 220V/380V |
| Weight | 23 | Dimension(l*w*h) | 435*211*334 |
| Efficiency (%) | 80 | Protection Class | IP21 |
| No-load Voltage (V) | DC310V | Insulation Class | F |
| High Light | IP21 Portable Plasma Cutter,AC380V Portable Plasma Cutter,Plasma Portable Metal Cutting Machine |
||
Product Description
CUTC60 Portable Plasma Cutter Function IP21 Air Pump IGBT Plasma Cutter,Cutting Machine
| FEATURES | ||||||||
| .Built in Air Pump IGBT Air Plasma Cuter,Cutting Machine with MMA Function | ||||||||
| .Using advanced IGBT module technology and soft-switching technology | ||||||||
| · Cutting capacity increases 1.8 times higher in cutting speed comparing with flame cutter. | ||||||||
| · Advamced pilot arc system design,100% arc start,arc continuously | ||||||||
|
· Bulit-in over current,over heat,less voltage,lack of phase protections,more safety on operation. |
||||||||
| · Suitable for cutting stainless steel, copper, iron and aluminum metal etc. | ||||||||
| · Simple operation and smooth cutting surface. | ||||||||
| · HF touched Arc-starting cutting |
| TECHNICAL PARAMETER | ||||||
| Item | CUT60 | CUT60S | CUT60L | |||
| Input power source(±15% 50/60HZ) | 1~AC380V | 1~AC220V | 1~AC380/220V | |||
| Rated Input current (A) | 12.3 | 45 | 45/12.3 | |||
| Rated input power capacity (KVA) | 8.1 | 9.9 | 9.9/8.1 | |||
| Output current range (A) | 20-60 | 20-60 | 20-60 | |||
| No-load voltage (V) | DC310V | DC310V | DC310V | |||
| Cutting Thickness | 1-20mm | 1-20mm | 1-20mm | |||
| Rated duty cycle (%) @40℃ | 60 | 60 | 60 | |||
| Efficiency (%) | 80 | 80 | 80 | |||
| Power factor (cosφ) | 0.93 | 0.73 | 0.93 | |||
| Protection class | IP21 | IP21 | IP21 | |||
| Insulation class | F | F | F | |||
| Dimensions (mm) | 435*211*334 | |||||
| Weight (Kg) | 23 | 23 | 23 | |||
