IGBT Module 380V MIG Stick Welding Machine 3Phase Digital Control
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Mig Welder | Key Words | Mig Welding Machines |
|---|---|---|---|
| Technology | IGBT Module Inverter | OEM/ODM | Optional |
| Function | Mig Mma Welding Machines | Dimension | 550*280*435 |
| Current | 400A | Voltage | AC 380V |
| Power Factor | 0.93 | Rated Load Duration(%) | 60 |
| High Light | IGBT Module MIG Stick Welding Machine,380V MIG Stick Welding Machine,3 Phase MIG MMA Welder |
||
Product Description
IGBT Module 380V 3Phase Digital Control MIG Stick Welding Machine
MIG Welder Features:
1. IGBT inverter with MIG,MMA.
2. Digital panel,current/voltage preview function,wide range match in current and voltage.
3. Auto protection of over-voltage and over-current.
4. 2T/4T Operation:2T is suit for spot welding and simple work ,4T is fit for continous long-term welding.
5. Cooling method:Forced air cooling.
Specification:
| Type | MIG400I | |
| control mode | IGBT inverter | |
| Rated input voltage | AC380V | |
| Input power frequency(HZ) | 50/60 | |
| Rated input capacity(KVA) | 22 | |
| Rated input current(A) | 33 | |
| Cable cross-sectional area | mains input(mm2) | 6 |
| power output(mm2) | 35 | |
| ground wire(mm2) | 4 | |
| Rated output voltage(V) | 31.5 | |
| Rated load duration(%) | 60 | |
| Rated output no-load voltage(V) | 60 | |
| Adjustment range of welding current(A) | 40-400 | |
| Power factor | 0.93 | |
| Enclosure rating | IP21S | |
| Insulation rating | F | |
| Cooling method | Forced air cooling | |
| Dimensions(mm) | 550*280*435 | |
| Host weight(KG) | 30 | |
Company Information:
Shenzhen General Welder Technology Co., Ltd, located at Shajing Subdistrict, Bao'an district, Shenzhen city which is the core city for the inverter type welding and cutting machine. We focused on developing, marketing all kinds of welding and cutting machine and its related goods.
We have below series products:
*ARC welder series, including DIY product, light industry product, and heavy industry product.
*TIG welder series, including TIG&ARC series, TIG pulse series, TIG AC/DC series,
*MIG welder series, including integrated one and separated one, also the pulse MIG machine.
*Plasma cutting machine series including DIY series and heavy industry usage cutting machine.
*Submerge ARC welding machine.
We can also supply you the good quality spare parts of the welding machine. And the accessories of the welding machine.
Aiming to provide the best quality product at a competitive price for you. We want long and strong cooperation relationship with you, not short time.
Quality goes first, Price goes later. With quality and price, We can help your business grow up more quickly.
Last year our overseas market turnover is more than 30 million. We are aiming to do double this year.
Welcome, my friend. We are here and waiting for your inquiry.
Thanks and Best regards!
FAQ
Q:I have not heard of General Welder company before, are you a new company?
A:General Welder company was established since 2012 by a team of members with welding machines exceptional knowledge and with over 10 years of experience in the welding machines Industry.
Q:.Can you offer welding machines for testing?
A:Yes, we can offer welding machines for the test.
Q:What kind of welding machines warranty do you have?
A:We provide a 1-year warranty to most of our welding machines product. For more information, please send the product model and send an email to us.
Q:Why should I choose your welding machines?
A:This is a question in many buyers mind, we are a quality-based professional welding machines company with great products and service, and we are a skill-oriented company. We believe in smart work and hard work combined. We never lose sight of our customer's requirements. We provide world-class training sessions to our staff and our associates.
Q:Do you offer any welding machines technical support?
A:Yes, we have engineers ready to assist customers with welding machines technical support problems, any issues that may arise during the quoting or installation process, as well as aftermarket support.
