Good Performance Inverter MMA Welding Machine MIG630 3P 380V
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Mig Welder | Technology | IGBT Inverter |
|---|---|---|---|
| Voltage | AC 380V | Key Selling Points | Easy To Operate |
| OEM/ODM | Optional | Color | Optional |
| Current | 630A | Frequency | 50/60HZ |
| High Light | 380V MMA Welding Machine,3P MMA Welding Machine,3P MIG MMA Welder |
||
Product Description
Good Performance Inverter MIG630 3P 380V Welding Machine
Inverter Machine Features:
1 IGBT inverter Technology.
2 Adopt inverter technology, stable welding.
3 New arc control technology, arc choose is easy and efficient.
4 Wide welding current range, good performance under high-speed welding.
5 Multiple protection functions: output short-circuit protection, overheat protection, inverter overcurrent or overvoltage protection.
Technical parameters
|
Type |
MIG630 |
|
|
Control mode |
IGBT inverter |
|
|
Rated input voltage |
AC380V |
|
|
Input power frequency(HZ) |
50/60 |
|
|
Rated input current(A) |
82 |
|
|
Rated input capacity(KVA) |
54 |
|
|
Cable cross-sectional area |
Main input(MM2) |
10 |
|
Power output(MM2) |
70 |
|
|
Ground(MM2) |
4 |
|
|
Rated output voltage(V) |
44 |
|
|
Duty cycle(%) |
60 |
|
|
Rated output no-load voltage(V) |
75 |
|
|
Current adjustment range(A) |
80-630 |
|
|
Voltage adjustment range(V) |
17-44 |
|
|
Power factor |
0.93 |
|
|
Enclosure rating |
IP21S |
|
|
Insulation rating |
F |
|
|
Cooling method |
Air |
|
|
Weldable sheet thickness(MM) |
2.5-40 |
|
|
Adapt welding wire diameter(solid core)(MM) |
1.2/1.4/1.6 |
|
|
Adapt welding wire diameter(drug core)(MM) |
1.2/1.4/1.6 |
|
|
Dimensions(MM) |
620*310*650 |
|
|
Host weight(KG) |
40 |
|
Our factory
About us
We can supply:MIG MMA Welder,ARC Welder,TIG Welder,Plasma cutting .More than 10 years production experience of OEM & ODM ,Inverter DC MMA/TIG Welding Machine.Using advanced IGBT Technology,excellent arc performance with solid wire in short circuit,globular and spray transfers flux or metal-cored wires in globular and spray transfer modes and Auto protection of over-voltage and over-current.
FAQ
Q:.Can you offer welding machines for testing?
A:Yes, we can offer welding machines for the test.
Q:What kind of welding machines warranty do you have?
A:We provide a 1-year warranty to most of our welding machines product. For more information, please send the product model and send an email to us.
Q:Can I buy other factory's products directly from you?
A:Yes, of course. There are already many customers cooperating with us in this way. We have over 10 years .in the business with extensive knowledge of technology and market.Our good reputation in China has been awarded by Alibaba Group as its seleced business partner.
Q:Why should I choose your welding machines?
A:This is a question in many buyers mind, we are a quality-based professional welding machines company with great products and service, and we are a skill-oriented company. We believe in smart work and hard work combined. We never lose sight of our customer's requirements. We provide world-class training sessions to our staff and our associates.
Q:Are you a welding machines factory or trading company?
A:We are welding machines manufacturer as well as a trading company with more than 10 assembly product line and strict QC system and equipment, so we can meet both your quantity and quality demands.
