250 AMP MIG Stick Welder Three Phase MMA Built In Wire Feeder
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Mig Welder | Voltage | AC 380V |
|---|---|---|---|
| Phase | Three Phase | Efficiency | 80% |
| Power Factor | 0.73 | Current | 20-200A |
| Wire Feeder | Built-in | Key Words | Mig Welding Machines |
| Highlight | 250 AMP Mig Stick Welder,Three Phase 250 Amp Mig Welder,MMA 250 Amp Mig Welder |
||
Product Description
250 AMP MIG Stick Welder Three Phase MMA Built In Wire Feeder
MIG Stick Welder Features:
1. Adopt advanced IGBT inverter control technology,MIG/MMA Functions.
2. Small size,20KG wire spool build-in.
3. Easy arc-starting,with auto protection functions of over-current and over heat.
4. Excellent arc characteristics,stable arc,good welding performance,less splash&noise.
5. With high duty cycle,performance&efficiency,stepless adjustment for current,voltage,wire feed er speed.
6. Suitable for welding all kings of materials,such as carbon steel,alloy steel,cast iron and stainless steel etc.
7. With complete accessories:MIG torch,Electrode holder,earth clamp,welding cable.
8. Option: Lift TIG,Cel Welding,3P 380V.
Specification:
| Input Voltage(V) | AC380V±15% |
| Frequency(HZ) | 50/60 |
| Rated Input Current(A) | 37.4 |
| Output Current Range(A) | 50-200 |
| Rated Output Voltage(V) | 16.5-26.5 |
| Duty Cycle(%) | 60 |
| Power Factor | 0.73 |
| Efficiency(%) | 80 |
| Type of Wire Feeder | Built-in |
| Wire-feeding Speed(mm) | 2.5-18 |
| Housing Protection Grade | IP21 |
| Diameter of Wire | 0.8/1.0 |
| Insulation Grade | F |
| Plate Thickness(mm) | 0.8+ |
| Net Weight(KG) | 27 |
| Dimension(mm) | 505*203*375 |
Our factory
Our Services
1. Your inquiry related to our product & price will be replied within 24 hours
2. Well-trained & experienced staff are to answer all your inquiries in English
3. Working time: 8:00am ~17:30pm, Monday to Saturday. (UTC+8)
4. Customized solution & perfect after-sale service
5. For large order, engineer can be sent to your country for on-site mainternace
instructions.
6. Our advantage: (1)Competitive price (2). Good quality (3). Timely delivery (4) New model launch yearly(5) Own manufacturing (6) Own quality control.
FAQ
Q:I have not heard of General Welder company before, are you a new company?
A:General Welder company was established since 2012 by a team of members with welding machines exceptional knowledge and with over 10 years of experience in the welding machines Industry.
Q:.Can you offer welding machines for testing?
A:Yes, we can offer welding machines for the test.
Q:What kind of welding machines warranty do you have?
A:We provide a 1-year warranty to most of our welding machines product. For more information, please send the product model and send an email to us.
Q:How do your factory do regarding quality control?
A:Our factory has gained the certificate and ISO9002 authentication. Quality makes us who we are today. We focus on the welding machines quality from the very beginning to the end.
