Handheld 1064nm Fiber Laser Welding Machine For Automotive Industry
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Laser Classification | Optical Fiber Laser | Type | Handheld Fiber Laser Welding Machine |
|---|---|---|---|
| Control | Manual | Laser Wavelength | 1064 |
| Application | Automotive Industry, Powder Metallurgy, Manufacturing Industry | Pulse Width | 0.5~15ms |
| Highlight | Handheld Fiber Laser Welding Machine,1064nm Fiber Laser Welding Machine,1KW Fiber Laser Welder |
||
Product Description
Handheld Fiber Laser Welding Machine Equipment
Fiber Laser Welding Features
1 . The operation is simple, unexperienced people can also use it quickly.
2. The welding speed is super fast. A handheld laser welding machine can replace the output of 3 to 5 welders.
3 . Welding is without consumables, saving costs in production.
4 . After the welding is completed, the welding seam is smooth and white, without polishing.
5. The laser welding machine has concentrated energy, small heat reflection range, and the product is not easy to deform.
6. The laser welding machine has concentrated energy, and the welding intensity is very high.
7. The energy and power of the laser welding machine are digitally controlled, which can meet various welding requirements, such as complete penetration, penetration, spot welding, and so on.
Parameters:
| Model | RL-1000W |
| Laser Power | 1000W |
| Laser Type | Fiber |
| Wavelength | 1070nm |
| Voltage | 220V±10% / 50Hz / 30A |
| Gross Power | <8KW |
| Welding Thickness | < 8mm |
| Welding Gap Requirements | ≤0.5mm |
| Welding Speed | 0~120 mm/s |
| Welding Head Configuration | Swing Welding Head + Water Cooling (optional) |
| Laser Operation | Continuous/Modulation |
| Beam Divergence Angle | ≤1.2mrad/m |
| Welding Joint Interface | QBH |
| Fiber Wire Length | 10m |
| Spot Dia | 0.2-2mm Adjustable |
| Positioning | Red Pointer |
| Cooling System | Industrial Chiller |
| Operating Temperature | 15~35 ºC |
Package
Our Services
1. Your inquiry related to our product & price will be replied within 24 hours
2. Well-trained & experienced staff are to answer all your inquiries in English
3. Working time: 8:00am ~17:30pm, Monday to Saturday. (UTC+8)
4. Customized solution & perfect after-sale service
5. For large order, engineer can be sent to your country for on-site mainternace
instructions.
6. Our advantage: (1)Competitive price (2). Good quality (3). Timely delivery (4) New model
launch yearly(5) Own manufacturing (6) Own quality control
FAQ:
Q:Can you make your welding machines under my brand?
A:Yes, we can welding machines under your logo and it has the Minimum Order Quantity .
Q:I have not heard of General Welder company before, are you a new company?
A:General Welder company was established since 2012 by a team of members with welding machines exceptional knowledge and with over 10 years of experience in the welding machines Industry.
Q:.Can you offer welding machines for testing?
A:Yes, we can offer welding machines for the test.
Q:What kind of welding machines warranty do you have?
A:We provide a 1-year warranty to most of our welding machines product. For more information, please send the product model and send an email to us.
Q:How do your factory do regarding quality control?
A:Our factory has gained the certificate and ISO9002 authentication. Quality makes us who we are today. We focus on the welding machines quality from the very beginning to the end.
